CPU | ARM Cortex A53 Dual Core, 64bit | |
Chipset | 1.2GHz Hi3751 V310 | |
GPU | Mali-450 Quad-Core 3D GPU (supports OpenGL ES 2.0/1.1/1.0 OpenVG 1.1) | |
RAM | 1GB DDR3 as standard | |
Storage | 8GB | |
OS | Android 4.4.2 | |
Display | 21.5” TFT LCD, 1920 x 1080p, LVDS | |
Video-Input | Format | 480i, 576i |
Audio Input | CVBS Audio (L/R RCA input, 0.2 ~ 2.0 VRMS) | |
Audio Decode | Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS, DTS-HD,MPEG L1/L2, MP3, AAC_LC, HE_AACV2, LPCM, APE, FLAC, OggVorbis, ARM-NB, ARM-WB, G.711(u/a) | |
Video Output | CVBS Audio Frequency Response Max. Output Power | L/R RCA Output (250mVRMS ± 10%) 100Hz~15KHz@ ±3dB (0dB reference signal at 1KHz) 2x8W(8ohm) THD+N<10%@1KHz |
Power | DC 12V (DC input) | |
Connection | WIFI Ethernet Data Network | 802.11 b/g/n, built-in module optional, need ANT 10/100M auto-identification and DHCP, USB driver 3G/4G |
COMB Filter | 3D | |
Deinterlace | 3D | |
Work Temp. | -10~55°C | |
Storage Temp. | -10~60°C |
ΕΑΝ | CLE-ICS-SD20 |
---|---|
Εγκατάσταση | Όχι |
Χρώμα | Λευκό |
Brand | ICS |
Σύνδεση με καλώδιο | Ναί |
