Maximum print area: Width: 128mm (5.04") Length: 991mm (39") Resolution: 8 dots/mm (203dpi) Maximum print speed: 356mm (14") per second Physical characteristics: Width: 287.3mm (11.31") Depth: 517.5mm (20.38") Height: 393.7mm (15.5") Weight: 25kg (55lb) Media specifications: Label and liner width: 40mm (1.57") to 140mm (5.51") Ribbon width: 40mm (1.57") to 130mm (5.1")
Media Characteristics
Labels Max. roll size: • 203mm (8") O.D. on a 76mm (3") I.D. core Thickness (label & liner): • 0.076mm (0.003") to 0.305mm (0.012") Media type • Continuous fanfold, die-cut or black mark For optimum print quality and printer performance, use genuine Zebra Supplies. Ribbons Ribbon is recommended to be at least as wide as media. Max. roll size: • 81.3mm (3.2") O.D. on a 25.4mm (1") I.D. core Standard lengths: • 450m (1,476') or 300m (984'); provides 3:1 and 2:1 media roll-to-ribbon ratios Ribbon setup: • Ribbon wound ink-side out
