Maximum print area: Width: 216mm (8.5") Length: 991mm (39") Resolution: 8 dots/mm (203dpi), 12 dots/mm (300dpi) Maximum print speed: 203dpi: 254mm (10") per second, 300dpi: 152mm (6") per second Physical characteristics Width: 397.5mm (15.65") Depth: 495mm (19.5") Height: 393.7mm (15.5") Weight: 32.7kg (72lb) Media specifications Label and liner width: 108mm (4.25") to 224mm (8.8") Ribbon width: 108mm (4.25") to 220mm (8.6")
Media Characteristics
Labels Max. roll size: • 203mm (8") O.D. on a 76mm (3") I.D. core Thickness (label & liner): • 0.076mm (0.003") to 0.305mm (0.012") Media type • Continuous fanfold, die-cut or black mark For optimum print quality and printer performance, use genuine Zebra Supplies. Ribbons Ribbon is recommended to be at least as wide as media. Max. roll size: • 81.3mm (3.2") O.D. on a 25.4mm (1") I.D. core Standard lengths: • 450m (1,476') or 300m (984'); provides 3:1 and 2:1 media roll-to-ribbon ratios Ribbon setup: • Ribbon wound ink-side out
